At AyrKing, we’re proud to partner with Popeyes. Our team of food preparation specialists is always working to innovate solutions to increase the profitability and service excellence of your Louisiana kitchen.
Breader Blender Sifter Marinators

BBS Model BBSUL2934P

Ideal for boneless items, such as nuggets and chicken breasts, the BBSUL2934P makes good use of vertical space. With its 29” wide work area, overshelf and built-in ice bath, this narrow BBS packs an impressive feature set in a small horizontal footprint.
View Parts for this model

Brushes

White 20” sifter brush with aluminum shaft and thicker nylon bristles than black brush

20” stainless steel brush cover with 1.1875” collar

Wire shelf hanger with B219 brush post that hangs from existing shelving

Baskets

9.25″ x 7.875″ x 4.5″ half-size wire basket without front hook

11″ x 14″ x 4″ stainless steel rectangular coating/feathering basket

12” or 10” round stainless steel wire collection basket/skimmer

11.8″ x 11.8″ stainless steel wire skimmer with gray 14″ handle

8.25″ x 8.25″ stainless steel wire skimmer with blue 18″ handle

24″ x 16″ stainless steel landing basket either 2” or 4” high

Accessories

Pairs with 28” IB28 stainless steel ice bath, which fits inside

28” removable stainless steel ice bath

21.5″ stainless steel batter drip guard with full-size opening for left or right side

7.75″ deep white plastic breading lug with hole on bottom

16 1/4″ X 26 1/2″ X 10″ deep white plastic breading lug without hole

White plastic breading lug cover

7″ x 12.75″ x 6″ stainless steel 1/3 size dough ball or waste collection pan

Red rigid polypropylene plastic lug plug fits hole in B302 and B302G breading lugs

BBS Models BBSU8835RH and LH

Built to accommodate both bone-in and boneless offerings, such as tenders, the BBSU8835 comes configured for either right or left workflows. The 88” wide work area houses a sifter and built-in ice bath to keep chicken close at hand, saving time and increasing efficiency.
View Parts for this model

Brushes

White 24.5” sifter brush with aluminum shaft and thicker nylon bristles than black brush

24” long stainless steel, collarless brush cover and lug support with bar for cleaning brush

Wire shelf hanger with B219 brush post that hangs from existing shelving

Baskets

11″ x 14″ x 4″ stainless steel rectangular coating/feathering basket

11.8″ x 11.8″ stainless steel wire skimmer with gray 14″ handle

8.25″ x 8.25″ stainless steel wire skimmer with blue 18″ handle

24″ x 16″ stainless steel landing basket either 2” or 4” high

11.4″ X 10.4″ X 3.95″ stainless steel wire basket with 12″ handle

12” or 10” round stainless steel wire collection basket/skimmer

Accessories

24″ long stainless steel sifter screen with 1.5mm holes, notched at exit end

46″ X 14″ X 10″cold protein storage rail for BBSU8835 and BBSUL7335

9.5″ x 15” x 14.25″ stainless steel doughball pan

21.5″ stainless steel batter drip guard with full-size opening for left or right side

7.75″ deep white plastic breading lug with hole on bottom

16 1/4″ X 26 1/2″ X 10″ deep white plastic breading lug without hole

Red rigid polypropylene plastic lug plug fits hole in B302 and B302G breading lugs

9 1/2″ x 13″ x 10″ deep white plastic dough ball pan

White plastic breading lug cover

BBS Mini Model BBSU3515P28

Designed for limited kitchen space in mind, the BBSU3515P28 provides AyrKing quality at a more affordable price point. The unit’s 35” wide work area with ice bath brings BBS efficiency to smaller spaces.
View Parts for this model

Brushes

White 20” sifter brush with aluminum shaft and thicker nylon bristles than black brush

20″ collarless stainless steel brush cover and lug support with bar for cleaning brush

Wire shelf hanger with B219 brush post that hangs from existing shelving

Baskets

9.25″ x 7.875″ x 4.5″ half-size wire basket without front hook

Accessories

28” removable stainless steel ice bath for BBSU3515 sifter

20″ long notchless stainless steel sifter screen with 1.5mm holes

Red rigid polypropylene plastic lug plug fits hole in B302 and B302G breading lugs

8″ deep stainless steel full-size lug pan without hole

9 ½” x 13″ x 10″ white plastic dough ball pan

Stainless steel 2/3 size, 8″ deep, breading lug with rectangular hole

BBS Ice Models BBSUL7335RH or LH

Perfect for both bone-in and boneless offerings, such as tenders, the BBSUL7335 is available with either a right or left workflow. The 73” lateral work area includes a sifter and 3-pan ice bath, making it easy to keep proteins separate and at cold temperatures during prep.
View Parts for this model

Brushes

White 20” sifter brush with aluminum shaft and thicker nylon bristles than black brush

20″ collarless stainless steel brush cover and lug support with bar for cleaning brush

Wire shelf hanger with B219 brush post that hangs from existing shelving

Baskets

11.4″ X 10.4″ X 3.95″ stainless steel wire basket with 12″ handle

Accessories

Pairs with 28” IB28 stainless steel ice bath, which fits inside

28” removable stainless steel ice bath for BBSU3515 sifter

9.5″ x 15” x 14.25″ stainless steel doughball pan

7.75″ deep white plastic breading lug with hole on bottom

16 1/4″ X 26 1/2″ X 10″ deep white plastic breading lug without hole

White plastic breading lug cover

21.5″ stainless steel batter drip guard with full-size opening for left or right side

6″ deep stainless steel full-size pan

46″ X 14″ X 10″ cold protein storage rail for BBSU8835 and BBSUL7335

20″ long notchless stainless steel sifter screen with 1.5mm holes

Tumble Marinator M101120

When you want to speed up the marinating process, but don’t want to risk waste from preparing too much, tumble marinators are the way to go. At 33” high, the M101120 tumble marinator runs on 120V and works with all types of chicken, reducing marination time from hours to minutes with the same delicious results.
View Parts for this model

Parts

11 pin relay base for both 115V & 230V
• 11 pin relay base
• 115V or 230V
• For all marinators

3 AMP breaker for 115V marinators
• 3 AMP breaker
• For 115V tumble, double-door, and vacuum marinators

8 pin relay base for marinator and stirrer
• 8 pin relay base
• Works for either 115V or 230V
• For marinator and stirrer

8 pin, 115V relay, marinator and stirrer timer box
• 8 pin relay
• 115V
• For marinator and stirrer timer box

Blue star drive connection for marinator shaft
• Blue star drive connection for marinator drum shaft
• For tumble, double-door, and vacuum marinators

Digital timer base for marinators and stirrer timer (LSTB)
• Timer base for 370016 timer
• Used in all marinators (vacuum, tumble, and double door)
• Used in LSTB stirrer timer box

Digital Timer for marinators and stirrer timer (LSTB)
• Digital timer
• For tumble, double-door, and vacuum marinators
• Also for stirrer timer box (LSTB)

Marinator drum gasket
• Rubber drum gasket
• Goes around marinator drum opening, under lid
• For tumble, double-door, and vacuum marinators

Lid for tumble, double-door, and vacuum marinator drums
• Stainless steel
• Drum lid
• For tumble, double-door, and vacuum marinators

Green start button for BBS-EC sifters and marinators, includes green cover, B137C
• Round green start button switch
• For BBS-EC sifters and marinators
• 115v/230V
• Comes with cover, B137C

Marinator caster, for square leg
• Marinator caster
• 3.5″ with brake
• Formally known as 3600071
• For square leg

Marinator drive and slip clutch assembly
• Stainless steel marinator drive assembly, with slip clutch
• For tumble, double-door, and vacuum marinators

Marinator drive assembly
• Stainless steel marinator drive assembly
• For tumble, double-door, and vacuum marinators
• Limited qty available
• Transitioning to 5001996-122

White support bracket for drum shaft (pillow block bearing)
• White nylon support bracket for drum shaft
• Pillow block bearing
• For tumble and vacuum marinators
• Does not work on double-door marinators

Marinator motor box cover
• Stainless steel marinator motor box cover
• For tumble, double-door, and vacuum marinators

115V marinator motor
• 115V marinator motor
• For tumble, double-door, and vacuum marinators
• Replaces 5001996-027

Guard for emergency stop switch
• Stainless steel guard for emergency stop switch

Marinator motor compartment seal
• Rubber motor compartment seal
• For tumble, double-door, and vacuum marinators

Marinator motor mounting bracket
• Stainless steel motor mounting bracket
• For tumble, double-door, and vacuum marinators

O-ring for under white disk on marinator lid
• O-ring
• Goes under white plastic disk on marinator lid
• Part of lid handle assemlby
• For tumble, double-door, and vacumm marinators

Plastic disc under marinator drum lid handle
• White plastic disc under marinator drum lid handle

Red emergency stop switch for marinators
• Red emergency stop switch
• Used in tumble, vacuum, and double-door marinators

Silicon sheet, with holes, for mounting marinator motor to bracket
• Orange silicon sheet with holes
• For mounting marinator motor to bracket
• For tumble, double-door, and vacuum marinators

Slip-clutch wrench for marinator shaft adjustments
• Stainless steel 36mm open end wrench
• Holds shaft while adjusting slip-clutch
• For tumble, double-door, and vacuum marinators

Solid silicon sheet for under motor mounting
• Solid silicon sheet
• For under marinator motor, when mounting
• For tumble, double-door, and vacuum marinators

Stainless steel timer cover for marinators
• Stainless steel timer cover
• For tumble, double-door, and vacuum marinators

Timer mounting adapter for marinators and stirrer timer box
• Timer mounting adapter
• White plastic
• For tumble, double-door, and vacuum marinators
• For stirrer time box, LSTB

40.6L tumble marinator drum
• 40.6L stainless steel tumble marinator drum
• Not for use on vacuum marinator

Round green switch cover for B137 start switch
• Round green switch cover
• For B137 start switch
• For BBS-EC sifters and marinators

Accessories

96L vacuum marinator drum
• 96L (25.4 Gallon)
• Stainless steel
• Vacuum marinator drum
• Also fits on tumble marinator

Double Door tumble marinator drum
• 40.6L stainless steel tumble marinator drum
• Two chambers and two doors/gaskets
• Includes blue star and pillow block
• Not for use on vacuum marinator

• Stainless steel grid
• 18″ wide X 14″ long X 1 1/2″ deep
• Goes with B617, white tub and lid, sold separately

White plastic tub with lid
• white plastic tub, with lid
• 20 3/4″ wide X 16 3/4″ long X 6 3/4″ deep
• Stainless steel grid, B618, sold separately

Double Door Marinator M101120D2

Like the M101120, the M101120D2 works on 120V, perfectly marinating chicken in minutes. At 36” high, this double-door tumble marinator has a divider screen for separating proteins by size or type, such as thighs/legs and breasts/wings, saving even more time for high-volume operations.
View Parts for this model

Parts

11 pin relay base for both 115V & 230V
• 11 pin relay base
• 115V or 230V
• For all marinators

3 AMP breaker for 115V marinators
• 3 AMP breaker
• For 115V tumble, double-door, and vacuum marinators

8 pin relay base for marinator and stirrer
• 8 pin relay base
• Works for either 115V or 230V
• For marinator and stirrer

8 pin, 115V relay, marinator and stirrer timer box
• 8 pin relay
• 115V
• For marinator and stirrer timer box

Blue star drive connection for marinator shaft
• Blue star drive connection for marinator drum shaft
• For tumble, double-door, and vacuum marinators

Digital timer base for marinators and stirrer timer (LSTB)
• Timer base for 370016 timer
• Used in all marinators (vacuum, tumble, and double door)
• Used in LSTB stirrer timer box

Digital Timer for marinators and stirrer timer (LSTB)
• Digital timer
• For tumble, double-door, and vacuum marinators
• Also for stirrer timer box (LSTB)

Marinator drum gasket
• Rubber drum gasket
• Goes around marinator drum opening, under lid
• For tumble, double-door, and vacuum marinators

Lid for tumble, double-door, and vacuum marinator drums
• Stainless steel
• Drum lid
• For tumble, double-door, and vacuum marinators

Green start button for BBS-EC sifters and marinators, includes green cover, B137C
• Round green start button switch
• For BBS-EC sifters and marinators
• 115v/230V
• Comes with cover, B137C

Marinator caster, for square leg
• Marinator caster
• 3.5″ with brake
• Formally known as 3600071
• For square leg

Marinator drive and slip clutch assembly
• Stainless steel marinator drive assembly, with slip clutch
• For tumble, double-door, and vacuum marinators

Marinator drive assembly
• Stainless steel marinator drive assembly
• For tumble, double-door, and vacuum marinators
• Limited qty available
• Transitioning to 5001996-122

White support bracket for drum shaft (pillow block bearing)
• White nylon support bracket for drum shaft
• Pillow block bearing
• For tumble and vacuum marinators
• Does not work on double-door marinators

Marinator motor box cover
• Stainless steel marinator motor box cover
• For tumble, double-door, and vacuum marinators

115V marinator motor
• 115V marinator motor
• For tumble, double-door, and vacuum marinators
• Replaces 5001996-027

Guard for emergency stop switch
• Stainless steel guard for emergency stop switch

Marinator motor compartment seal
• Rubber motor compartment seal
• For tumble, double-door, and vacuum marinators

Marinator motor mounting bracket
• Stainless steel motor mounting bracket
• For tumble, double-door, and vacuum marinators

O-ring for under white disk on marinator lid
• O-ring
• Goes under white plastic disk on marinator lid
• Part of lid handle assemlby
• For tumble, double-door, and vacumm marinators

Plastic disc under marinator drum lid handle
• White plastic disc under marinator drum lid handle

Red emergency stop switch for marinators
• Red emergency stop switch
• Used in tumble, vacuum, and double-door marinators

Silicon sheet, with holes, for mounting marinator motor to bracket
• Orange silicon sheet with holes
• For mounting marinator motor to bracket
• For tumble, double-door, and vacuum marinators

Slip-clutch wrench for marinator shaft adjustments
• Stainless steel 36mm open end wrench
• Holds shaft while adjusting slip-clutch
• For tumble, double-door, and vacuum marinators

Solid silicon sheet for under motor mounting
• Solid silicon sheet
• For under marinator motor, when mounting
• For tumble, double-door, and vacuum marinators

Stainless steel timer cover for marinators
• Stainless steel timer cover
• For tumble, double-door, and vacuum marinators

Timer mounting adapter for marinators and stirrer timer box
• Timer mounting adapter
• White plastic
• For tumble, double-door, and vacuum marinators
• For stirrer time box, LSTB

Round green switch cover for B137 start switch
• Round green switch cover
• For B137 start switch
• For BBS-EC sifters and marinators

Double Door tumble marinator drum
• 40.6L stainless steel tumble marinator drum
• Two chambers and two doors/gaskets
• Includes blue star and pillow block
• Not for use on vacuum marinator

Accessories

96L vacuum marinator drum
• 96L (25.4 Gallon)
• Stainless steel
• Vacuum marinator drum
• Also fits on tumble marinator

• Stainless steel grid
• 18″ wide X 14″ long X 1 1/2″ deep
• Goes with B617, white tub and lid, sold separately

White plastic tub with lid
• white plastic tub, with lid
• 20 3/4″ wide X 16 3/4″ long X 6 3/4″ deep
• Stainless steel grid, B618, sold separately

40.6L tumble marinator drum
• 40.6L stainless steel tumble marinator drum
• Not for use on vacuum marinator

Connect with AyrKing

No matter where you are around the globe, AyrKing is always ready to help you find the right equipment solution for your operation. Use our convenient online locator to connect with a distributor or representative in your area.
CONTACT US
